Logitech Rally Plus Implementation: Hospital Conference Room Project Summary

  • Writer: Brian Bloom
    Brian Bloom
  • Aug 6
  • 4 min read

ree

Project Overview

We recently completed a comprehensive audiovisual upgrade for a major hospital's conference facilities, implementing Logitech Rally Plus systems in their executive conference room and Rally Bar Mini in smaller meeting spaces. This project involved transforming multiple conference rooms into state-of-the-art collaboration environments with enterprise-grade video conferencing capabilities.


Key Components Implemented

Executive Conference Room

  • Logitech Rally Plus Ultra-HD ConferenceCam with 4K video and intelligent auto-framing

  • Multiple Rally Mic Pods (4-7 units) with beamforming technology

  • Rally Mic Pod Hubs for flexible audio routing

  • Ceiling-mounted microphone arrays to address acoustic challenges

  • Logitech Tap Touch Controller for intuitive meeting control

  • 85" primary display with dual 50" secondary displays

  • Professional mounting infrastructure including camera, speaker, and hub mounts


Critical Issues Encountered and Solutions

Dual Monitor Resolution Challenges

One of the most significant technical challenges we encountered involved resolution compatibility issues when using dual monitors with the Rally Plus system. Here's what we discovered:

The Problem:

  • When connecting two displays of different native resolutions, the system struggled to maintain consistent output

  • Secondary monitors would either display incorrectly scaled content or fail to display at all

  • The Rally Display Hub's automatic EDID detection created conflicts between mismatched displays

The Solution: 1080p EDID Implementation

  • We implemented a 1080p EDID emulator between the Rally Display Hub and the displays

  • This forces all connected displays to operate at a standardized 1080p resolution

  • Benefits include:

    • Consistent scaling across all displays

    • Elimination of resolution negotiation conflicts

    • Simplified troubleshooting for IT staff

    • Reliable performance across different display manufacturers


Understanding Rally Plus Limitations

Content Sharing Requirements

The Rally Plus system has specific requirements for content sharing that are crucial to understand:

Essential Components for Content Sharing:

  1. Dedicated PC/Computer - Required for content sharing through the Tap controller

  2. HDMI connectivity from the PC to the Rally system

  3. Proper network configuration for wireless sharing options

  4. Compatible software platforms (Teams, Zoom, etc.)

Important Limitation: Collaboration OS devices (Android-based room systems) do not support content sharing through the Logitech Tap controller. You must use a Windows PC or similar computer for this functionality.


Audio Coverage Limitations

  • Maximum of 7 Rally Mic Pods supported

  • Each mic pod covers approximately 15' diameter

  • Mic pods should be spaced 8 feet apart for optimal coverage


Ceiling-Mounted Microphone Considerations

Acoustic Challenges Addressed

The hospital's conference room featured a three-wall configuration with one open side, creating unique acoustic challenges:

Issues:

  • Significant reverberation and echo from the open wall

  • External noise pickup from adjacent areas

  • Uneven audio coverage for participants


Ceiling Mount Solution: We implemented ceiling-mounted Rally Mic Pods to address these challenges:

  1. Optimal Placement: Mics mounted at 8-foot intervals across the ceiling

  2. Height Considerations: Best performance with ceilings 10 feet or lower

  3. Cable Management: Used plenum-rated cables routed through ceiling tiles

  4. Coverage Pattern: Created overlapping audio zones for consistent pickup


Installation Best Practices for Ceiling Mounts

  • Use Rally Mic Pod Mounts (available in white or graphite)

  • Route cables through conduit for clean appearance

  • Position mics directly above seating areas

  • Test extensively with higher ceilings (may need closer spacing)

  • Consider HVAC noise and position mics away from vents


Tips and Tricks for Rally Plus Deployment

Pre-Installation Planning

  1. Infrastructure Assessment

    • Verify electrical outlet locations near display mounting positions

    • Confirm network drops for all connected devices

    • Plan cable routing paths before installation

    • Check ceiling height for microphone placement

  2. Room Acoustics Evaluation

    • Test for echo and reverberation

    • Identify potential noise sources

    • Consider acoustic treatments if needed


Configuration Best Practices

Display Setup:

  • Always use matching displays when possible

  • If mixing display sizes, implement EDID management

  • Mount primary display at eye level for seated participants

  • Position secondary displays for optimal viewing angles

Audio Configuration:

  • Enable Speaker Boost Mode when using only external mics (3dB increase)

  • Position first mic pod 12' from the video bar

  • Use Rally Mic Pod Hubs for U-shaped or irregular table configurations

  • Test all seating positions for audio coverage

Network and Platform Integration:

  • Configure Quality of Service (QoS) for video traffic

  • Test all major platforms (Teams, Zoom, WebEx) before deployment

  • Set up room calendar integration for scheduling displays

  • Enable automatic firmware updates during off-hours


ree


Common Caveats and Solutions

Caveat 1: USB Extension Limitations

  • Rally system USB cables have length limitations

  • Solution: Use Rally Table Hub for longer distances

Caveat 2: Firmware Compatibility

  • Different firmware versions can cause issues

  • Solution: Update all components simultaneously

Caveat 3: Platform-Specific Features

  • Some features work differently on Teams vs. Zoom

  • Solution: Train users on platform-specific functionality

Caveat 4: Cable Management Complexity

  • Multiple cables can create installation challenges

  • Solution: Use Rally cable retention brackets and proper conduit


Professional Services Value

Our team's expertise in navigating these complex deployments ensures:

  • Proper equipment selection for room size and configuration

  • Optimal microphone placement for complete coverage

  • Resolution of technical issues like dual-monitor compatibility

  • Comprehensive testing across all platforms

  • User training on system features

  • Ongoing support for system optimization


Conclusion

The Logitech Rally Plus system offers exceptional video conferencing capabilities when properly configured. Understanding its limitations—particularly around content sharing requirements and display resolution management—is crucial for successful deployment. Our experience with ceiling-mounted microphones, EDID management, and platform integration ensures that organizations can fully leverage these powerful collaboration tools while avoiding common pitfalls.


Whether implementing Rally Plus for large conference rooms or Rally Bar Mini for smaller spaces, professional installation and configuration make the difference between a functional system and an exceptional collaboration environment. The key is understanding both the capabilities and limitations of the technology, then designing around them for optimal performance.
